    The Textile Fabrics Vertical Flame Resistance Performance Test Apparatus

    Ask Lasest Price
    Brand Name : CHENGFENG
    Model Number : CF8425
    Certification : ISO,CE
    Price : US$2000-$30000
    Payment Terms : T/T,Cash,L/C,Western Union,MoneyGram
    Supply Ability : 5 units per month
    Delivery Time : 10 Work Days
    • Product Details
    • Company Profile

    The Textile Fabrics Vertical Flame Resistance Performance Test Apparatus

    Scope of application:
    The Textile Fabrics Vertical Flame Resistance Performance Test Apparatus is designed for measuring the vertical flame spread for children’ sleepwear, fabrics, other textile materials or resilient filling materials used in upholstered furniture.
    Standards:
    CFR 1615/1616,CA TB117,ASTM D6413,ISO6940/6941,EN 14878,EN 1103.
    Technical Parameters:
    Combustion test box: 329x329x767mm, the top of the box is evenly arranged with 6 holes with a diameter of 12.5mm
    Test clip: made of stainless steel, 2.0mm thick, 422mm long, 89mm wide
    Power supply: 220V ± 10%, 50HZ, 100W;
    Gas source: Industrial grade methane gas or other fuel gas (such as household liquefied petroleum gas, natural gas, coal gas, etc.)
    Ignition: 11mm caliber, 25 degree angle to vertical
    Timing device: combustion timing, stop combustion timing, 99.99 / h / m / s accurate to 0.01h / m / s
    Two flow meters
    Heavy hammer: 54.5g 113.4g 226.8g 340.2g 453.6g
    Flame height: 40mm
    With medical absorbent cotton.
    Sample size: 300x80mm
    Laboratory burner for Bunsen burner
